XGG2-88Z1 by johnson electric
Image is representational - see mfr. specs

XGG2-88Z1

Johnson Electric

Switch Snap Action N.O./N.C. SPDT Plunger Faston 15A 250VAC 3.2N Screw Mount ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The XGG2-88Z1 is a miniature microswitch featuring a plunger actuator and Faston terminals, designed for general-purpose switching applications in household appliances and industrial equipment. It is rated for 250 VAC at 16 A (ENEC) or 15 A (UL/CSA) with silver/silver-nickel (Ag/AgNi10) contacts in a changeover (CO) configuration. The switch has an actuating force of 3.20 ozf, an operating position of 11.43 mm, and a circuit differential of 0.57 mm, with dimensions of 27.8 × 15.9 × 10.3 mm. It operates reliably across a temperature range of -40 °C to +150 °C, achieves a mechanical life of 2.5 × 105 cycles minimum (up to 50 × 106 cycles maximum), and is compliant with IEC 60335-1 (4th edition). The switch is commonly used in appliance control circuits, safety interlocks, and general-purpose switching where compact size and long operational life are required.

Search Keywords: XGG288Z1

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Johnson Electric
部件编号:
XGG2-88Z1
计量单位:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Polyoxymethylene/Plunger
Contact Rating @ Voltage:
15@250VAC@UL A
Maximum Movement Differential:
0.35 mm
Operating Force:
3.2 N
Termination Style:
Quick Connect
Body Orientation:
Straight
IP Rating:
IP40

有存货: 2,780

Ships today, if you order in

库存数量的起订量: 10

缺货数量的起订量: 1500

工厂交货期 14 周

PRICE (USD)

数量
Unit Price
10
$4.62
250
$2.74
500
$2.42
1,000
$2.08
1,500
$2.07
3,000
$2.06
4,500
$2.05
6,000 +
$2.04
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南
