MS3102R22-14S by itt cannon
Image is representational - see mfr. specs

MS3102R22-14S

ITT CANNON

The MS3102R22-14S is a MIL-DTL 5015 Series I circular connector, configured as a box mounting receptacle with 19 size 16 socket contacts. ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The MS3102R22-14S is a circular connector from the MIL-DTL 5015 Series I, designed as a box mounting receptacle with threaded coupling. It features a size 22 shell with a 22-14 contact arrangement, housing 19 size 16 socket contacts with solder cup terminations. The copper alloy contacts have hard silver plating and are rated for 22 A, with a contact resistance of 6 mΩ. Built for reliability, this connector operates in temperatures from -55°C to +125°C, offers 500 hours of salt spray resistance, and is rated for a minimum of 500 mating cycles. Its robust construction makes it suitable for demanding military, industrial, and commercial applications where a secure and durable connection is required.

Search Keywords: MS3102R2214S

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
ITT CANNON
部件编号:
MS3102R22-14S
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694020
COO:
MX
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1

有存货: 0

缺货数量的起订量: 13

工厂交货期 10 周

数量
Unit Price
13
$60.70
25
$38.85
38
$30.35
50 +
$29.74
Log in for special pricing Click for Quote Price Match Request
