描述
The PCS-E20LB is a vertical type die-cast material backshell for standard cable, part of the PCS series 1.27 mm pitch connector family designed for high-density board-to-cable interfaces in downsized electronic equipment. This 20-contact backshell features an EMI-filtered design to meet FCC and other standards, with a robust interface structure and quick locking via metal latch. The connector accommodates cables with an outside diameter of approximately ø7.5 mm and includes a cable clamp, latch mechanism, and Phillips head screws for secure mounting. The backshell dimensions are 30.0 mm (A) × 20.3 mm (B) with an 8×7 mm cable outlet (C), making it suitable for office automation equipment and other applications requiring compact, reliable interconnections with low insertion force and drainage structure for flux removal.
搜索关键词: PCSE20LB
规格
FREQUENTLY ASKED QUESTIONS
Is PCS-E20LB RoHS compliant?
Yes, PCS-E20LB is RoHS compliant.
What is the lead time for PCS-E20LB?
The standard lead time for PCS-E20LB is approximately 26 days. In-stock quantities ship from Master Electronics.
有存货: 137
发货 today, 输入设置值。
最小订购数量: 20
工厂交货期 26 周
价格 (USD)
工具/3D模型
产品指南
数据表
