GSXA42D
MICRO SWITCH™ Hazardous Location Safety Limit Switches: GSX Series, Red Epoxy-Coated Aluminum Housing, Top Roller Lever with Roller to Left and Hinge to Right, 2 NC/1 NO Slow Action Break Before Make Contacts, AC-15, A300 / DC-13, Q300, NEMA 1, 3, 4, 12, 13, and IP67 Seal Rating, Operating Temperature: -40 °C to 70 °C [-40 °F to 158 °F], 1/2 - 14 NPT Conduit Termination, NEMA 7: Class I, Div. 1 & 2, Groups B, C & D; NEMA 9: Class II, Div. 1 & 2, Groups E, F, & G; Ex d IIC T6 ta -40 °C to +70 °C Gb / Ex tb IIIC T85 °C Db, Agency Approvals: ATEX (CE), cULus, IEC Ex, KOSHA, INMETRO, External and Internal Ground Screw ...
描述
The HONEYWELL GSXA42D MICRO SWITCH Hazardous Location Safety Limit Switch is ideal for use in challenging environments. With a red epoxy-coated aluminum housing, this switch features a top roller lever with roller to the left and hinge to the right. It has 2 normally closed/1 normally open slow action break before make contacts, suitable for AC-15, A300/DC-13, Q300 applications. This switch is rated for NEMA 1, 3, 4, 12, 13, and IP67 seal rating, ensuring reliable performance in various conditions. It has an operating temperature range of -40°C to 70°C [-40°F to 158°F] and 1/2 - 14 NPT conduit termination. Additionally, it has NEMA 7: Class I, Div. 1 & 2, Groups B, C & D; NEMA 9: Class II, Div. 1 & 2, Groups E, F, & G hazardous location ratings. With ATEX (CE), cULus, IEC Ex, KOSHA, and INMETRO approvals, this switch is suitable for use in different regions. The external and internal ground screw feature enhances safety and reliability.
搜索关键词: GSXA42D
规格
常见问题
GSXA42D 是否符合 RoHS 标准？
是的，GSXA42D 符合 RoHS 标准。
GSXA42D 的交货期是多少？
GSXA42D 的标准交货期约为 71 周。有库存的数量由 Master Electronics 发货。
有存货: 0
已订购:
4
可以发货 11/5/26
工厂交货期 71 周
