GLDA01A2A

MICRO SWITCH™ Global Miniature Limit Switches: GLD Series, EN50047 Mounting Standard, Thermoplastic Housing, Side Rotary, Adjustable Roller Lever, Ø 19 mm x 6 mm [0.75 in x 0.24 in] Nylon Roller, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, AC 15, A300; DC 13, Q300, 0.5 in - 14 NPT Conduit, Operating Temperature: -40 °C to 85 °C [-40 °F to 185 °F], IP 67; NEMA 1, 4X (Indoor), 12, and 13, Agency Approvals: CE, CCC, CSA, UL ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The HONEYWELL GLDA01A2A is a MICRO SWITCH„¢ Global Miniature Limit Switch with a thermoplastic housing and EN50047 mounting standard. It features a side rotary mechanism with an adjustable roller lever, measuring 19 mm x 6 mm [0.75 in x 0.24 in], and nylon roller. This limit switch has a 1NC 1NO Single Pole Double Throw (SPDT) snap action contact type, making it suitable for a wide range of applications. It has an AC 15, A300; DC 13, Q300 electrical rating and a 0.5 in - 14 NPT conduit for easy installation. The operating temperature ranges from -40 °C to 85 °C [-40 °F to 185 °F], and it has an IP 67; NEMA 1, 4X (Indoor), 12, and 13 protection rating. The GLDA01A2A is CE, CCC, CSA, and UL approved, ensuring its reliability and safety.

产品亮点:

  • Designed to IEC standard for world-wide applications
  • UL, CSA, and CE
  • International conduit sizes
  • Direct PLC interface compatible (two circuit)
  • Modular construction reduces maintenance parts costs
  • Designed for ease of installation
  • Variety of basic switch versions
  • Wide choice of actuators

搜索关键词: GLDA01A2A

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Honeywell
部件编号:
GLDA01A2A
计量单位:
每 Each
RoHS:
Yes
HTS:
8536509040
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
10
类型:
Miniature
致动器样式:
Side Rotary with Roller
极-位配置:
SPDT
开关配置:
N.O./N.C.
操作力:
0.12 N
尺寸:
30.5mm x 44.2mm x 147 mm
最大电流额定值:
6@120VAC A
端子类型:
Conduit
NEMA外壳防护标准等级:
1, 4, 12, 13
本体方向:
Right Angle

常见问题

GLDA01A2A 是否符合 RoHS 标准？

是的，GLDA01A2A 符合 RoHS 标准。

GLDA01A2A 的交货期是多少？

GLDA01A2A 的标准交货期约为 26 周。有库存的数量由 Master Electronics 发货。

有存货: 122

可立即发货

工厂交货期 26 周
