BZ-2R

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 15 A 125/250 Vac, ENEC 16 A 250 Vac, Pin Plunger, Solder Termination, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The Honeywell BZ-2R Snap Action Switch is used for simple or precision on/off application needs. A Snap Action Switch is a type of momentary contact micro switch which operates at a rapid speed as it takes very little force or stimulus to operate. This SPDT snap switch is widely used in irrigation systems, timing devices, office equipment, medical and dental equipment, semi-trailer trucks, manually operated devices, and valves.

The BZ-2R Snap Action Switch from Honeywell comes with low operating force and differential travel for reliable functionality. Featuring a choice of actuation, termination and operating characteristics, this Honeywell switch is ideal for a variety of industrial and mechanical applications. The elongated mounting hole in this snap action switch enables easier and more accurate mounting. This standard basic switch has a long mechanical life of up to 20,000,000 cycles with 95% survival rate.

产品亮点:

  • Elongated mounting hole for easier, more accurate mounting
  • Current rating ranges from 15 A to 25 A
  • Accepted world-wide standard "Large Basic" switch
  • Long mechanical life up to 20,000,000 cycles at 95% survival
  • Choice of actuation, termination and operating characteristics
  • Low operating force and differential travel

潜在应用:

  • Irrigation systems
  • Semi-trailer trucks
  • Timing devices
  • Office equipment
  • Test instruments
  • Medical/dental equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

搜索关键词: BZ2R

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Honeywell
部件编号:
BZ-2R
计量单位:
每 Each
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
50
安装方式:
Through Hole
极-位配置:
SPDT
开关配置:
N.O./N.C.
致动器材质/样式:
Pin Plunger
触点额定电流 @ 电压:
186.42 A
最大动作差:
0.05 mm
操作力:
3.61 N
端接方式:
Solder
尺寸:
49.28 x 17.45 x 22.61 mm
本体方向:
Straight
IP等级:
N/A

FREQUENTLY ASKED QUESTIONS

Is BZ-2R RoHS compliant?

Yes, BZ-2R is RoHS compliant.

What is the lead time for BZ-2R?

The standard lead time for BZ-2R is approximately 13 days. In-stock quantities ship from Master Electronics.

有存货: 478

发货 today, 输入设置值。

最小订购数量: 5

工厂交货期 13 周

价格 (USD)

数量
单价
5
$14.37
25
$13.32
50
$12.53
100
$11.85
250
$11.71
500
$11.68
1,000 +
$11.65
