BX2P4L by honeywell
图片仅供参考 - 请查看制造商规格
Honeywell 授权经销商

BX2P4L

The BX2P4L is a low-differential, momentary side rotary limit switch with a stainless steel housing, designed for use in hazardous locations. ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The BX2P4L is a hazardous location limit switch from the MICRO SWITCH™ BX2 Series, featuring a corrosion-resistant stainless steel housing. It provides 2NC-2NO DPDT snap-action switching with silver contacts and is designed for low differential travel of 4° maximum. This momentary, side-rotary switch has a maximum operating torque of 0.45 Nm, a maximum pretravel of 9°, and a minimum overtravel of 66°. It operates reliably in a wide temperature range from -40 °C to 70 °C and includes a 0.75-14 NPT conduit entry. With its rugged, weather-sealed construction, the BX2P4L is ideal for demanding applications in explosive environments such as chemical plants, off-shore drilling sites, and pipelines.

搜索关键词: BX2P4L

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Honeywell
部件编号:
BX2P4L
计量单位:
每 Each
RoHS:
Yes
HTS:
85365030
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1
类型:
Explosion Proof
致动器样式:
Side Rotary
极-位配置:
DPDT
开关配置:
N.O./N.C.
操作力:
N/A
尺寸:
N/A
最大电流额定值:
N/A
端子类型:
Conduit
NEMA外壳防护标准等级:
1, 3, 4, 6, 7, 9, 13
本体方向:
Right Angle

常见问题

BX2P4L 是否符合 RoHS 标准？

是的，BX2P4L 符合 RoHS 标准。

BX2P4L 的交货期是多少？

BX2P4L 的标准交货期约为 29 周。有库存的数量由 Master Electronics 发货。

有存货: 5

可立即发货

工厂交货期 29 周

价格 (USD)

数量
单价
1
$3,851.23
3
$3,841.60
5 +
$3,832.00
登录以获取特别价格 点击询价 价格匹配请求

工具/3D模型

产品指南

产品更改
