914CE3-6 by honeywell
图片仅供参考 - 请查看制造商规格
Honeywell 授权经销商

914CE3-6

MICRO SWITCH™ Medium-Duty Limit Switches: 914CE Series Miniature Enclosed Switch, Top Roller Perpendicular Plunger Actuator, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, 6 ft UL Cable ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The 914CE3-6 Limit Switch from Honeywell is a medium-duty, miniature and enclosed limit switch. Limit Switches are generally used to control machinery in industrial applications. They function as a safety interlock and can be used to establish or disrupt electrical connections. The cable or connector and basic switch terminals of this Honeywell Switch are encased in an epoxy compound to provide superior resistance even in harsh environment applications.

Featuring a fluorocarbon diaphragm sealing, this Limit Switch offers stable and reliable protection. It is available with low temperature variants, as well as a side and bottom exit cable/connector. These limit switches are generally used in processing equipment, textile machinery, machine tools, robotics, packaging equipment, farm machinery, commercial laundry equipment, printing trade machinery, and vehicles, among others.

产品亮点:

  • Die-cast Zinc housing
  • Compact construction
  • Gang mounting capability
  • Side and bottom exit cable/connector
  • Simple two-screw mounting
  • Low temperature variants
  • Fluorocarbon sealing (standard)
  • Pre-wired or connector versions
  • Cable length variations
  • Wide selection of actuators

潜在应用:

  • Processing Equipment
  • Textile Machinery
  • Machine Tools
  • Robotics
  • Packaging Equipment
  • Farm Machinery
  • Commercial Laundry Equipment
  • Printing Trade Machinery
  • Vehicles

搜索关键词: 914CE36

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Honeywell
部件编号:
914CE3-6
计量单位:
每 Each
RoHS:
Yes
HTS:
8536509055
COO:
GB
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
10
类型:
Miniature
致动器样式:
Cross Roller Plunger
极-位配置:
SPDT
开关配置:
N.O./N.C.
操作力:
12 N
尺寸:
40 x 16 x 67 mm
最大电流额定值:
5@250VAC A
端子类型:
Wire Lead
NEMA外壳防护标准等级:
1, 2, 3, 3R, 4, 6, 6P, 13
本体方向:
Straight

常见问题

914CE3-6 是否符合 RoHS 标准？

是的，914CE3-6 符合 RoHS 标准。

914CE3-6 的交货期是多少？

914CE3-6 的标准交货期约为 15 周。有库存的数量由 Master Electronics 发货。

有存货: 12

发货 today, 输入设置值。

已订购: 30   可以发货 12/9/26

工厂交货期 15 周

价格 (USD)

数量
单价
1
$192.26
5
$181.06
10
$176.48
20
$174.24
50
$173.81
100 +
$173.37
