4TL1-3D by honeywell
Image is representational - see mfr. specs

4TL1-3D

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, 4 Pole Double Throw (4PDT) 2 Position (On - On), Screw Terminals, Locking Lever (Locked Out Of Center Position), Military Part Number MS24660-23D ...

产品说明书
符合 RoHS 规定
Bulk 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 4TL1-3D Toggle Switch from Honeywell is ideal for various military, aerospace and other harsh environment applications. This Honeywell Toggle Switch features environment-proof sealing, temperature resistance and silver cadmium oxide contacts. It is also designed with a pull-to-unlock toggle lever to avert accidental operation. Toggle Switches are manually actuated by means of a projecting lever, such as mechanical lever, handle or a rocking mechanism.

This In-Line Toggle Switch enables both maintained and momentary toggle action. These electrical switches are available in different styles and sizes. They are generally used in industrial machinery and equipment, military and commercial aviation, construction equipment, test instruments, agricultural machinery, process control, and medical instrumentation, among others.

Product Highlights:

  • UL recognized, CSA certified
  • CE approved
  • Qualified to MIL-DTL-3950
  • 1, 2, and 4 pole circuitry
  • Environment-proof sealing
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Completely sealed switching chamber
  • Temperature range: -85°F to +160°F
  • Step-design case provides added space between terminals to help prevent shorting

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: 4TL13D

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Honeywell
部件编号:
4TL1-3D
Alias/AKA:
MS24660-23D
计量单位:
Per Each
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bulk
Pole Throw Configuration:
4P2T (4PDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
20@28VDC A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.5 x 41.6 x 72.9 mm
Operating Temperature:
-65 to 71 °C

有存货: 471

可立即发货

已订购: 200   可以发货 6/11/26

工厂交货期 9 周

数量
Unit Price
1
$91.16
5
$90.11
10
$88.34
20
$86.34
50
$84.85
100 +
$84.42
