3LS1

MICRO SWITCH™ General Purpose Limit Switches: LS Series, Epoxy-Coated Zinc Housing, Non Plug-in Body Style, Side Roller Plunger, Ø 16,7 mm x 4,8 mm [0.66 in x 0.19 in] SST Roller, Roller Plunger May Be Locked in Any Position Through 360°, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Double Break, 10 A 120, 240, or 480 Vac, 0.5 in - 14 NPT Conduit, Operating Temperature: -29 °C to 71 °C [-20 °F to 160 °F], NEMA 1, 3, 4, 6 and 13 ...

查看数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The HONEYWELL part 3LS1 is a MICRO SWITCH„¢ General Purpose Limit Switch that features an epoxy-coated zinc housing and a non-plug-in body style. It has a side roller plunger with a diameter of 16.7 mm and a thickness of 4.8 mm. The switch is equipped with a stainless steel roller with a diameter of 0.66 in and a thickness of 0.19 in.The unique design of this limit switch allows the roller plunger to be locked in any position through 360°, providing versatility in various applications. It has a 1NC 1NO single pole double throw (SPDT) snap action, double break configuration.With a current rating of 10 A and voltage options of 120, 240, or 480 Vac, this switch is capable of handling a wide range of electrical loads. It features a 0.5 in - 14 NPT conduit for easy installation and is designed to operate in temperatures ranging from -29 °C to 71 °C (-20 °F to 160 °F).The 3LS1 limit switch has a NEMA 1, 3, 4, 6, and 13 rating, making it suitable for use in various indoor and outdoor environments. It is a reliable and durable solution for applications that require accurate and dependable position sensing.

产品亮点:

  • Mode of operation is field adjustable
  • NEMA 1, 3, 4, 6, and 13
  • Wide choice of heads and actuators
  • Variety of operating characteristics
  • Captive screws
  • UL and CSA approved parts available

潜在应用:

  • Machine tools
  • Conveyors
  • Material handling
  • Metal fabrication equipment
  • Lift trucks

搜索关键词: 3LS1

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Honeywell
部件编号:
3LS1
计量单位:
每 Each
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
10
类型:
Enclosed
致动器样式:
Side Roller Plunger
极-位配置:
SPDT
开关配置:
N.O./N.C.
操作力:
40.03 N
尺寸:
39.88 x 70.33 x 93.98 mm
最大电流额定值:
0.8@115VDC A
端子类型:
Conduit
NEMA外壳防护标准等级:
1, 3, 4, 6, 13
本体方向:
Right Angle

常见问题

3LS1 是否符合 RoHS 标准？

是的，3LS1 符合 RoHS 标准。

3LS1 的交货期是多少？

3LS1 的标准交货期约为 40 天。有库存的数量由 Master Electronics 发货。

有存货: 9

发货 today, 输入设置值。

已订购: 25   可以发货 12/21/26

工厂交货期 40 周
