26PC05SMT by honeywell
Image is representational - see mfr. specs

26PC05SMT

Honeywell

Honeywell Miniature SMT Low Pressure Sensors: 26PC Series, Wet/Wet Differential Sensing, Compensated/Unamplified, 5 psi Pressure Range, Port 1: Standard Configuration, Port 2: Standard Configuration ...

产品说明书
符合 RoHS 规定
Tube 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

26PC05SMT Board Mount Pressure Sensor from Honeywell comes with alignment pins for position accuracy. The SMT series pressure sensors are small and low cost, but deliver high value. The design flexibility of this Differential Pressure Sensor reduces installation costs and eliminates secondary operations by enabling it to be used with other SMT components on a PCB.

A pressure sensor is an electromechanical pressure-sensing device which detects the pressure applied and converts it into an electrical signal. Board Mount Pressure Sensors are designed for various industrial and mechanical applications that perform according to the changing pressure. Honeywell Sensors are widely used in medical, industrial and environmental applications like Continuous Positive Airway Pressure equipment, blood glucose monitors, oxygen conservers, residential fuel cells, and soft drink dispensing, etc.

Product Highlights:

  • Maximum peak reflow temperature of 260 °C [500 °F]
  • Gage, vacuum gage, differential gage, wet/wet differential sensing available in one package
  • Proven elastomeric interconnections of the 20PC family
  • Temperature compensation
  • End point calibration
  • Sensor consists of only five components
  • Elastomeric construction
  • Wide operating temperature range of -40 °C to 85 °C [-40 °F to 185 °F]
  • Alignment pins for position accuracy
  • Small package size (less than one half the size of the 26PC) and compact surface mount profile
  • True wet/wet differential sensing

Search Keywords: 26PC05SMT

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Honeywell
部件编号:
26PC05SMT
计量单位:
Per Each
RoHS:
Yes
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Tube
Mounting:
PCB Surface Mount
Accuracy:
±0.5 %
Device Pressure Type:
Differential
Operating Pressure Range:
0 to 5 psi
Media:
Air,Gas,Liquid
Output Voltage:
0 to 50 mV
Response Time:
1 mS
Typical Operating Supply Voltage:
10 V
Operating Temperature:
-40 to 85 °C
Dimension:
10.92 x 6.1 x 7.87 mm

有存货: 291

可立即发货

工厂交货期 12 周

数量
Unit Price
1
$114.04
5
$106.91
10
$103.83
20
$100.76
50
$96.70
100 +
$93.63
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
