1XE1

MICRO SWITCH™ Subminiature Environmentally Sealed Basic Switches: XE Series, Single Pole Double Throw (SPDT), 7 A at 28 Vdc, Stainless Steel Enclosure, (3) 305 mm [12 in] Lead Wire Termination (20 Gage), -53 °C to 105 °C [-65 °F to 221 °F] Temperature Range, Military Part Number MS27994-1 ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

One of the defining features of a Snap Action Switch is that a small movement of the actuator can produce a comparatively large movement at electrical contacts. The XE Series switches come with environmental sealing in a small package for stringent indoor or outdoor applications, where the risk of contamination is high. They are best suited for the aircraft industry or moist and dusty industrial environments.

1XE1 Snap Action Switch from Honeywell has a watertight seal per MIL-S-8805 and a temperature tolerance to 105 °C [221 °F]. It also comes equipped with high temperature tolerance of up to 105 °C [221 °F] and a power load switching capability of up to 7 A.

产品亮点:

  • Very small package size
  • Power load switching capability to 7 A
  • Temperature tolerance to 105 °C [221 °F]
  • High temperature construction for use to 149 °C [300 °F]
  • Watertight seal per MIL-S-8805, enclosure design symbol 3
  • Choice of actuation

潜在应用:

  • Aircraft
  • Ordinance
  • Moist or dusty industrial environments

搜索关键词: 1XE1

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Honeywell
部件编号:
1XE1
别名/又称:
MS27994-1
计量单位:
每 Each
RoHS:
Yes
HTS:
8536509065
COO:
US
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1
安装方式:
Through Hole
极-位配置:
SPDT
开关配置:
N.O./N.C.
致动器材质/样式:
Steel/Pin Plunger
触点额定电流 @ 电压:
7@115VAC 28VDC A
最大动作差:
0.13 mm
操作力:
4.73 N
端接方式:
Wire Lead
尺寸:
15.65 x 8.03 x 18.92 mm
本体方向:
Straight
IP等级:
N/A

常见问题

1XE1 是否符合 RoHS 标准？

是的，1XE1 符合 RoHS 标准。

1XE1 的交货期是多少？

1XE1 的标准交货期约为 17 周。有库存的数量由 Master Electronics 发货。

有存货: 43

可立即发货

已订购: 100   可以发货 11/2/26

工厂交货期 17 周
