1TL1-1 by honeywell
Image is representational - see mfr. specs

1TL1-1

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, Single Pole Double Throw (SPDT) 3 Position (On - Off - On), Screw Terminals, Standard Lever, Military Part Number MS24523-21. ...

产品说明书
符合 RoHS 规定
Box 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The HONEYWELL part 1TL1-1 is a highly reliable MICRO SWITCHâ„¢ toggle switch designed for various applications. It is part of the TL series and features a single pole double throw (SPDT) configuration with three positions: On - Off - On. This toggle switch is equipped with screw terminals for easy and secure wiring connections. It comes with a standard lever and meets military specifications under the part number MS24523-21. With its excellent quality and durability, the HONEYWELL part 1TL1-1 is a top choice for industrial and military applications.

Product Highlights:

  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85°F to +160°F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: 1TL11

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Honeywell
部件编号:
1TL1-1
Alias/AKA:
MS24523-21
计量单位:
Per Each
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
745.7@(CSA/UL) A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
28.4mm x 15.7mm x 63.47mm
Operating Temperature:
-65 to 71 °C

有存货: 588

可立即发货

已订购: 400   可以发货 6/5/26

工厂交货期 6 周

数量
Unit Price
1
$33.67
5
$22.86
10
$21.97
25
$20.85
50
$20.74
100
$20.04
250 +
$19.64
