M80-8891005 by harwin
图片仅供参考 - 请查看制造商规格
Harwin 授权经销商

M80-8891005

Conn Datamate F 10 POS 2mm Crimp ST Top Entry Cable Mount Bulk/Loose ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The M80-8891005 is a DATAMATE 2 mm pitch crimp DIL socket assembly with large bore design for 22 AWG wire termination. It features a glass-filled PBT UL94V-0 moulding with beryllium copper clips and copper alloy shell, finished with nickel plating and 0.30 µm gold clip with 0.28 µm gold shell. The connector is rated for 3.0 A maximum at 25 °C and 2.2 A at 85 °C, with a working voltage of 120 V AC/DC and voltage proof of 360 V AC/DC. Contact resistance is 20 mO maximum initially and 25 mO maximum after conditioning, with insulation resistance of 1000 mO minimum initially and 100 mO minimum after conditioning. The assembly is designed for reliable interconnection in industrial and telecommunications applications requiring crimp-style termination with consistent electrical performance across extended temperature ranges.

搜索关键词: M808891005

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Harwin
部件编号:
M80-8891005
计量单位:
每 Each
RoHS:
Yes
HTS:
8536904000
COO:
GB
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1

常见问题

M80-8891005 是否符合 RoHS 标准？

是的，M80-8891005 符合 RoHS 标准。

M80-8891005 的交货期是多少？

M80-8891005 的标准交货期约为 9 周。有库存的数量由 Master Electronics 发货。

有存货: 82

可立即发货

最小订购数量: 5

工厂交货期 9 周

价格 (USD)

数量
单价
5
$7.94
25
$6.29
100
$5.74
250
$5.38
500
$5.11
1,000
$4.87
2,500
$4.86
5,000 +
$4.84
登录以获取特别价格
