C4D0212N-A by electroswitch
图片仅供参考 - 请查看制造商规格
Electroswitch 授权经销商

C4D0212N-A

Fully Enclosed Rotary Switch - 2 Pole - 2 to 12 Position Adjustable - Non-Shorting - 0.5A@28VDC/0.3A@125VAC - Diallyl phthalat - 30° Index - Solder Terminals ...

查看数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The ELECTROSWITCH part C4D0212N-A is a high-quality fully enclosed rotary switch that is designed for easy installation and reliable performance. This switch is a 2 pole switch with 2 to 12 adjustable positions, allowing for versatile functionality. With its non-shorting feature, this switch ensures accurate and reliable signal transmission. It has a maximum rating of 0.5A at 28VDC and 0.3A at 125VAC, making it suitable for a variety of applications. The switch features a durable construction with a diallyl phthalate housing, providing excellent resistance to heat, chemicals, and impact. Operating on a 30° index, this switch allows for precise positioning and efficient operation. It is equipped with solder terminals, ensuring secure and stable electrical connections. Whether for industrial, commercial or residential use, the ELECTROSWITCH part C4D0212N-A is a reliable and versatile rotary switch that delivers exceptional performance and durability.

搜索关键词: C4D0212NA

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Electroswitch
部件编号:
C4D0212N-A
计量单位:
每 Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1
位置数量:
12
极-位配置:
DP12T
致动器长度:
12.7 mm
尺寸:
38.1 x 38.1 x 42.34 mm
致动器样式/直径:
Flatted Shaft/6.35
安装方式:
Panel Mount
本体方向:
Straight
端子类型:
Solder
切换角度:
30 °
触点额定电流 @ 电压:
0.5@28VDC A

常见问题

C4D0212N-A 是否符合 RoHS 标准？

是的，C4D0212N-A 符合 RoHS 标准。

C4D0212N-A 的交货期是多少？

C4D0212N-A 的标准交货期约为 8 天。有库存的数量由 Master Electronics 发货。

有存货: 20

可立即发货

已订购: 100   可以发货 9/30/26

工厂交货期 8 周

价格 (USD)

数量
单价
1
$50.91
5
$40.63
10
$38.08
25
$34.59
50
$32.78
100
$29.34
250 +
$28.03
登录以获取特别价格 点击询价 价格匹配请求
