D2E146-HT67-01 by ebm-papst
图片仅供参考 - 请查看制造商规格
ebm-papst 授权经销商

D2E146-HT67-01

AC Blower Centrifugal Ball Bearing - 230V - 171 x 196 x 110 mm - 623.9CFM - 63dBA - 2100RPM. ...

查看数据表 询问数据表
符合 RoHS
Box 包装
附件
请求编程报价
合规证书

描述

The D2E146-HT67-01 is a 230VAC Centrifugal Blower with a calotte bearing and hot galvanized sheet steel impeller. This AC fan comes with forward curved, dual inlet, black PP plastic housing and terminal box. The motor features that an anti-vibration mounted on both sides (motor suspension) and has thermal overload protector (TOP) wired internally. The surface of the rotor is partially cast in aluminum. The electrical connection is with the plug via terminal box. The rotational direction is counter clockwise direction seen on rotor.

搜索关键词: D2E146HT6701

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
ebm-papst
部件编号:
D2E146-HT67-01
计量单位:
每 Each
RoHS:
Yes
HTS:
8414596560
COO:
EU
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1
封装类型:
Box
类别:
AC Blower
尺寸:
171 x 196 x 110 mm
电压额定值:
230 V
额定功率:
355 W
最大风量:
412 CFM
噪声水平:
66 dB
特殊功能:
None
端接方式:
Terminals
外壳材料:
Plastic
工作温度:
-25 to 55 °C

FREQUENTLY ASKED QUESTIONS

Is D2E146-HT67-01 RoHS compliant?

Yes, D2E146-HT67-01 is RoHS compliant.

What is the lead time for D2E146-HT67-01?

The standard lead time for D2E146-HT67-01 is approximately 17 days. In-stock quantities ship from Master Electronics.

  提供不同的包装选项。  查看替代品

有存货: 0

已订购: 10   可以发货 8/31/26
已订购: 9   可以发货 10/5/26

工厂交货期 17 周
