描述
The 249-7967-3732-504F is a green LED panel mount indicator designed for front or rear panel mounting in process control and status indication applications. This stovepipe-style indicator operates at 3.6 V DC with a current draw of 20 mA and delivers a typical intensity of 100 mcd, providing clear visual feedback in industrial environments. The indicator features an aluminum black-anodized housing with phosphor bronze fused tin terminals for wire wrapping electrical connections, and mounts through a 0.375" (9.53 mm) clearance hole with a maximum panel thickness of 0.312" (7.92 mm). Operating reliably across a temperature range of -55°C to +71°C, this complete package includes the light source, housing, and lens, making it suitable for power indication, maintenance warnings, and instrumentation applications where robust, long-lasting visual signaling is required.
搜索关键词: 24979673732504F
规格
FREQUENTLY ASKED QUESTIONS
Is 249-7967-3732-504F RoHS compliant?
Yes, 249-7967-3732-504F is RoHS compliant.
What is the lead time for 249-7967-3732-504F?
The standard lead time for 249-7967-3732-504F is approximately 26 days. In-stock quantities ship from Master Electronics.
有存货: 140
发货 today, 输入设置值。
最小订购数量: 15
工厂交货期 26 周
数据表
