FFB0424VHN by delta thermal / emi / solenoids
Image is representational - see mfr. specs

FFB0424VHN

Delta Thermal / EMI / Solenoids

DC Fans DC Axial Fan - 40x28mm - 24VDC ...

产品说明书
符合 RoHS 规定
Bulk 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

Delta Electronics FFB DC Axial Fans are built for high performance and feature a dual blade as well as a high air flow rotating stator blade. Delta FFB standard DC axial fan series has a plastic impeller and frame, as well as Delta’s maintenance-free ball bearing system. FEATURES Bearing type - ball bearing Impeller and frame material - plastic (UL 94V-0) Lead wires UL 1007 AWG #24 or equivalent Red wire positive (+) Black wire negative (-) Voltage - Rated 24VDC Size / Dimension Square - 40mm L x 40mm H Width 28.00mm Air Flow 15.8 CFM (0.442m³/min) Static Pressure 0.509 in H2O (126.8 Pa) Bearing Type Ball Fan Type Tubeaxial Noise 45.0 dB(A) Power (Watts) 2.40W RPM 9500 RPM Termination 2 Wire Leads

Search Keywords: FFB0424VHN

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Delta Thermal / EMI / Solenoids
部件编号:
FFB0424VHN
计量单位:
Per Each
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
288
Package Type:
Bulk
Category:
DC Fan
Dimension:
40 x 40 x 28 mm
Voltage Rating:
24 V
Power Rating:
2.4 W
Maximum Airflow:
15.7CFM
Noise Level:
45 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-10 to 70 °C

有存货: 2,365

可立即发货

Minimum Order Quantity: 5

工厂交货期 32 周

数量
Unit Price
5
$13.05
25
$11.11
50
$11.03
100
$10.98
288
$10.95
576
$10.92
1,152 +
$10.90
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南
