AFB0612DH-TP11 by delta thermal / emi / solenoids

AFB0612DH-TP11

Axial Square-60mm L x 60mm H x 25.4 mm W 12VDC 4 Wire Leads Speed Sensor (Tach) PWM Control ...

查看数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

Delta Electronics Ingress Protection Fans feature built-in resistance to environmental conditions such as dust, water and foreign objects that can disable and damage fans and thermal cooling equipment. Delta Electronics Ingress Protection (IP) fans provide IP55 and higher protection as an industry standard, offering protection against the intrusion of solid objects such as hands and fingers, as well as dust or dirt exposure, accidental contact, and water in the form of salt fog, moisture, or precipitation. Voltage - Rated 12VDC Size / Dimension Square - 60mm L x 60mm H Width 25.40mm Air Flow 50.4 CFM (1.41m³/min) Bearing Type Ball Fan Type Tubeaxial Features PWM Control, Speed Sensor (Tach) Noise 55.0 dB(A) Power (Watts) 10.10W RPM 9000 RPM Termination 4 Wire Leads Operating Temperature 14 ~ 158°F (-10 ~ 70°C) Weight 0.176 lb (79.83g) Current Rating (Amps) 0.840A Voltage Range 10.8 ~ 13.2VDC

搜索关键词: AFB0612DHTP11

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Delta Thermal / EMI / Solenoids
部件编号:
AFB0612DH-TP11
计量单位:
每 Each
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
供应商标准包装: 供应商原始包装中所含物品的数量、长度、重量或体积,以便高效存储、搬运和配送。
180
类别:
DC Fan
尺寸:
60 x 60 x 25.4 mm
电压额定值:
12 V
额定功率:
10.08 W
最大风量:
50.4 CFM
噪声水平:
55 dB
转速计信号:
Yes
PWM控制信号:
Yes
特殊功能:
Tachometer Output, PWM speed control
端接方式:
Lead Wires
外壳材料:
Plastic
工作温度:
-10 to 70 °C

常见问题

AFB0612DH-TP11 是否符合 RoHS 标准?

是的,AFB0612DH-TP11 符合 RoHS 标准。

AFB0612DH-TP11 的交货期是多少?

AFB0612DH-TP11 的标准交货期约为 46 周。有库存的数量由 Master Electronics 发货。

有存货: 0

缺货数量的起订量: 135

工厂交货期 46 周

价格 (USD)

数量
单价
135
$36.04
270
$19.02
405
$13.08
540 +
$12.82
