AFB0412SHB-SP04 by delta thermal / emi / solenoids
Image is representational - see mfr. specs

AFB0412SHB-SP04

Delta Thermal / EMI / Solenoids

DC Fans DC Axial Fan - 40x15mm - 12VDC - 14.83CFM - 1.92W - 0.16A - 41.5dBA - 11000RPM - Ball Bearing - PWM ...

产品说明书
符合 RoHS 规定
Bulk 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

Delta Electronics Ingress Protection Fans feature built-in resistance to environmental conditions such as dust, water and foreign objects that can disable and damage fans and thermal cooling equipment. Delta Electronics Ingress Protection (IP) fans provide IP55 and higher protection as an industry standard, offering protection against the intrusion of solid objects such as hands and fingers, as well as dust or dirt exposure, accidental contact, and water in the form of salt fog, moisture, or precipitation. Voltage - Rated 12VDC Size / Dimension Square - 40mm L x 40mm H Width 15.00mm Air Flow 14.8 CFM (0.414m³/min) Bearing Type Ball Fan Type Tubeaxial Features PWM Control, Speed Sensor (Tach) Noise 41.5 dB(A) Power (Watts) 1.92W RPM 11000 RPM Termination 4 Wire Leads Operating Temperature 14 ~ 158°F (-10 ~ 70°C) Weight 0.055 lb (24.95g) Current Rating (Amps) 0.160A Voltage Range 10.8 ~ 13.2VDC

Search Keywords: AFB0412SHBSP04

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Delta Thermal / EMI / Solenoids
部件编号:
AFB0412SHB-SP04
计量单位:
Per Each
RoHS:
Yes
HTS:
8414596590
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
448
Package Type:
Bulk
Category:
DC Fan
Dimension:
40 x 40 x 15 mm
Voltage Rating:
12 V
Power Rating:
1.92 W
Maximum Airflow:
14.8 CFM
Noise Level:
41.5 dB
Tachometer Signal:
Yes
PWM Control Signal:
Yes
Special Features:
Tachometer Output, PWM speed control
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-10 to 70 °C

有存货: 401

可立即发货

已订购: 2,688   可以发货 11/23/26

Minimum Order Quantity: 5

工厂交货期 39 周

数量
Unit Price
5
$12.03
25
$10.20
50
$10.12
100
$10.07
448
$10.05
896
$10.02
1,344 +
$10.00
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南
