MMWA2P1K-F by cornell dubilier
Image is representational - see mfr. specs

MMWA2P1K-F

Cornell Dubilier

Metalized Polyester Film Capacitor - Axial - 0.1uF (+/-) 10% - 250VDC - 0.24in(6.1mm) Dia x 0.24in(6.1mm) - –55 °C to 125 °C ...

产品说明书
符合 RoHS 规定
BAG 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

MMWA2P1K-F is a Type MMWA metallized polyester film capacitor with axial leads designed for 250 Vdc applications. This capacitor features a capacitance of 0.100 µF with ±10% tolerance and incorporates compact, non-inductive extended windings with epoxy end seals to provide excellent moisture resistance and capacitance stability across the operating temperature range of -55°C to 125°C. The metallized polyester construction provides self-healing characteristics that help prevent permanent shorting due to high voltage transients. With a dissipation factor of 0.75% maximum at 25°C and 1 kHz, and an insulation resistance of 10,000 MO × µF (minimum 30,000 MO), this capacitor is well-suited for general-purpose filtering, coupling, and decoupling applications in electronic circuits requiring reliable high-voltage performance.

Search Keywords: MMWA2P1KF

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Cornell Dubilier
部件编号:
MMWA2P1K-F
计量单位:
Per Each
RoHS:
Yes
HTS:
8532250060
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
BAG
Dielectric:
PET
Voltage:
200,250 VDC|VAC
Capacitance Value:
0.1 uF
Tolerance:
10 %
Mounting:
Through Hole
Termination Style:
Axial
Size:
6.1 x 17.4 mm

有存货: 415

可立即发货

库存数量的起订量: 10

缺货数量的起订量: 250

工厂交货期 26 周

PRICE (USD)

数量
Unit Price
10
$5.06
50
$5.04
100
$5.03
250
$5.02
500
$3.09
750
$2.44
1,000 +
$2.40
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南
