21FD3725A-F by cornell dubilier
图片仅供参考 - 请查看制造商规格
Cornell Dubilier 授权经销商

21FD3725A-F

AC Motor Run Capacitor - Oil Filled -25uF (+/-) 10% - 370VDC - 1-3/4 in Round - 70°C - 50 to 60 Hz - Aluminum Housing - RoHS ...

查看数据表 询问数据表
符合 RoHS
BOX 包装
附件
请求编程报价
合规证书

描述

21FD3725A-F is an AC motor run capacitor from the Type MPF series, designed for reliable alternating current applications. This oil-filled metallized polypropylene capacitor features a 25.0 µF capacitance with ±10% tolerance and a rated voltage of 370 Vac. It is housed in a round aluminum case (Style 21) with dimensions of 1¾" diameter and 2.84" height, featuring tin plated steel terminals with 4-prong quick disconnect configuration. The capacitor is internally protected with a pressure sensitive interrupter for fail-safe operation and operates at temperatures up to 70°C. Common applications include air conditioning, refrigeration, power factor correction, and motor-run circuits where low dissipation factor and compact size are essential.

搜索关键词: 21FD3725AF

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Cornell Dubilier
部件编号:
21FD3725A-F
计量单位:
每 Each
RoHS:
Yes
HTS:
8532250020
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1
封装类型:
BOX

常见问题

21FD3725A-F 是否符合 RoHS 标准？

是的，21FD3725A-F 符合 RoHS 标准。

21FD3725A-F 的交货期是多少？

21FD3725A-F 的标准交货期约为 15 周。有库存的数量由 Master Electronics 发货。

有存货: 97

可立即发货

工厂交货期 15 周

价格 (USD)

数量
单价
1
$22.27
5
$21.50
10
$20.99
25
$20.67
50
$20.23
100
$19.82
250 +
$19.57
