PN-1320-MB by bud industries
图片仅供参考 - 请查看制造商规格
Bud Industries 授权经销商

PN-1320-MB

Light Gray Polycarbonate Wall Mount NEMA 4X Enclosure - External 2.52 x 2.28 x 1.38 Inches - Internal 2.28 x 2.05 x 1.18 Inches ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The PN-1320-MB is a NEMA 4X plastic enclosure box constructed from polycarbonate material with an external mounting bracket, designed for harsh industrial environments. The enclosure features a light gray body and cover, manufactured from UL94-HB polycarbonate that is UV stabilized, with a service temperature range of -40°C to +120°C. The box includes mounting bosses that accept M3 x 4mm or #4 x 3/16" self-tapping screws, and external mounting holes that accept M4 or #8 pan head screws. The cover is secured to the body with four M4x0.7 x 20mm stainless steel screws supplied with the unit. This enclosure is ideal for protecting electrical and electronic components in outdoor and corrosive environments where NEMA 4X compliance and UV resistance are required.

搜索关键词: PN1320MB

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Bud Industries
部件编号:
PN-1320-MB
计量单位:
每 Each
RoHS:
Yes
HTS:
8538100000
COO:
TW
ECCN:
EAR99
供应商标准包装: 供应商原始包装中所含物品的数量、长度、重量或体积,以便高效存储、搬运和配送。
1
本体材料:
Polycarbonate
本体颜色:
Light Gray
安装方式:
Wall Mount
类别:
Enclosure

常见问题

PN-1320-MB 是否符合 RoHS 标准?

是的,PN-1320-MB 符合 RoHS 标准。

PN-1320-MB 的交货期是多少?

PN-1320-MB 的标准交货期约为 2 周。有库存的数量由 Master Electronics 发货。

有存货: 100

可立即发货

制造商库存: 8,637   可以发货 11/30/26

最小订购数量: 5

工厂交货期 2 周 可以发货 12/1/26

价格 (USD)

数量
单价
5
$7.47
25
$6.58
50
$6.52
100
$6.31
250
$6.28
500
$6.26
1,000 +
$6.25
