SRN5020-220M by bourns
Image is representational - see mfr. specs

SRN5020-220M

Bourns

Inductor Power Semi-Shielded Wirewound 22uH 20% 100KHz 11Q-Factor Ferrite 1A 312mOhm DCR 2020 T/R ...

产品说明书
符合 RoHS 规定
REEL 包装
附件
Request Programming Quote
Discontinued & Replaced
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

SRN5020-220M is a semi-shielded power inductor from Bourns designed for DC/DC converter applications and portable electronics. It features a 22 µH inductance with 20% tolerance, a maximum DC resistance of 0.312 O, and a rated RMS current of 1.0 A with a saturation current of 0.90 A. The inductor operates over a temperature range of -40°C to +125°C and has a self-resonant frequency of 13 MHz at 2.52 MHz test frequency. Its compact semi-shielded construction with a maximum component height of 2 mm, combined with ferrite core and enameled copper wire, makes it ideal for space-constrained applications such as notebook computers, digital video cameras, and LCD display systems.

Search Keywords: SRN5020220M

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Bourns
部件编号:
SRN5020-220M
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MY
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
2000
Package Type:
REEL
Inductance:
22 uH
Type:
Power
Impedance:
N/A
Tolerance:
20 %
Technology:
Wirewound
Maximum DC Current:
1 A
Maximum DC Resistance:
312 mOhm
Operating Temperature:
-25 to 120 °C
Packaging:
Tape and Reel
Protection Style:
Semi-Shielded
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

有存货: 6,000

Ships today, if you order in

Minimum Order Quantity: 2000

Multiple: 2000

数量
Unit Price
2,000
$0.4891
4,000
$0.4737
6,000
$0.4713
8,000
$0.4690
10,000
$0.4621
26,000
$0.4505
50,000
$0.4482
100,000 +
$0.4147
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
建议的换货
SRN5020TA-220M
SRN5020TA-220M
