SRN1060-330M by bourns
Image is representational - see mfr. specs

SRN1060-330M

Bourns

Inductor Power Semi-Shielded Wirewound 33uH 20% 100KHz 16Q-Factor Ferrite 3.15A 72mOhm DCR T/R ...

产品说明书
符合 RoHS 规定
REEL 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The SRN1060-330M is a semi-shielded power inductor from Bourns' SRN1060 series, featuring a nominal inductance of 33 µH with ±20% tolerance. This component is engineered for high-current DC/DC converter applications with an RMS current rating of 3.15 A and a saturation current of 2.80 A, combined with a maximum DC resistance of 0.072 O. The inductor exhibits a self-resonant frequency of 7 MHz at a test frequency of 2.52 MHz, with a quality factor of 16, and operates reliably with a temperature rise of 40°C at rated current. The semi-shielded ferrite core construction with enameled copper wire and magnetic epoxy resin coating provides excellent performance while maintaining RoHS compliance and halogen-free status. This inductor is widely used in notebook computers, digital video cameras, televisions, and LCD display power management circuits where compact size and high current handling are essential.

Search Keywords: SRN1060330M

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Bourns
部件编号:
SRN1060-330M
计量单位:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
600
Package Type:
REEL
Inductance:
33 uH
Type:
Power
Impedance:
N/A
Tolerance:
20 %
Technology:
Wirewound
Maximum DC Current:
3.15 A
Maximum DC Resistance:
0.072 Ohm
Operating Temperature:
-40 to 125 °C
Packaging:
Tape and Reel
Protection Style:
Semi-Shielded

有存货: 4,800

Ships today, if you order in

Minimum Order Quantity: 600

Multiple: 600

工厂交货期 14 周

数量
Unit Price
600
$0.3891
1,200
$0.3609
3,000
$0.3600
5,400
$0.3365
7,800
$0.3356
10,200
$0.3276
15,000
$0.3268
25,200 +
$0.3192
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南
