SM91072AL-E

The SM91072AL-E is an AEC-Q200 compliant, single-port 10/100 Base-T LAN transformer designed to meet IEEE 802.3u standards. ...

产品说明书

符合 RoHS 规定

REEL 包装

Certificate of Compliance Guarantee

描述

The SM91072AL-E is an AEC-Q200 compliant 10/100 Base-T transformer designed for Ethernet applications. It meets IEEE 802.3u standards and features a turns ratio of 1:1 (±2%) for both transmit and receive channels, with a minimum Open Circuit Inductance (OCL) of 350 µH under an 8 mA DC bias. The device offers a low insertion loss of -1.1 dB maximum from 1-100 MHz and provides high isolation rated at 1500 Vrms. Due to its expanded operating temperature range of -40 to +125 °C and AEC-Q200 compliance, this transformer is well-suited for automotive and industrial applications requiring robust network connectivity.

Product Highlights:

Potential Applications:

Search Keywords: SM91072ALE

规格

Product Attribute

Attribute Value

Select Attribute

Products found: 0

供应商:

Bourns

部件编号:

SM91072AL-E

计量单位:

Per Each

RoHS:

Yes

HTS:

8504312000

COO:

ECCN:

EAR99

Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
