RLB9012-101KL by bourns
Image is representational - see mfr. specs

RLB9012-101KL

Bourns

Inductor Power Wirewound 100uH 10% 1KHz 20Q-Factor Ferrite 1.4A 280mOhm DCR RDL Bag ...

产品说明书
符合 RoHS 规定
TRAY 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

RLB9012-101KL is a radial leaded inductor from the Bourns RLB9012 series, designed for general-purpose power supply and DC/DC converter applications. It features a 100 µH inductance value measured at 1 kHz with ±10% tolerance, a Q reference of 20 at 0.796 MHz test frequency, and a minimum self-resonant frequency (SRF) of 3.70 MHz. The inductor is constructed with a ferrite DR core and enameled copper wire, with Cu/Ag/Sn terminals, and operates over a temperature range of -55°C to +125°C. With a maximum DC resistance of 0.280 ohms and a maximum rated DC current of 1.40 A, this RoHS-compliant component is well-suited for power electronics where reliable inductance and low losses are required.

Search Keywords: RLB9012101KL

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Bourns
部件编号:
RLB9012-101KL
计量单位:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
TRAY
Inductance:
100 uH
Type:
Power
Impedance:
N/A
Lead Pitch:
5 mm
Tolerance:
10 %
Technology:
Wirewound
Maximum DC Resistance:
280 mOhm
Maximum DC Current:
1.4 A
Protection Style:
N/A
Packaging:
Bag

有存货: 3,050

Ships today, if you order in

Minimum Order Quantity: 200

Multiple: 200

工厂交货期 14 周

PRICE (USD)

数量
Unit Price
200
$0.2889
600
$0.2585
2,600
$0.2489
5,000
$0.2407
7,600
$0.2401
10,000
$0.2395
15,000
$0.2377
25,000 +
$0.2348
Suppliers Standard Package
