RJR26FX202P by bourns
Image is representational - see mfr. specs

RJR26FX202P

Bourns

Res Cermet Trimmer 2K Ohm 10% 0.25W(1/4W) 0.1% 12(Elec)Turns 1.78mm (7.37 X 4.32 X 6.35mm) Pin Thru-Hole Tube ...

产品说明书
不符合 RoHS 规定
TUBE 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The RJR26FX202P is a 1/4" multiturn cermet trimming potentiometer (Trimpot) designed for precision adjustment applications in industrial environments. It features a 2 kO nominal resistance value with ±100 ppm/°C temperature coefficient, 0.25 watt power rating at 85°C, and operates across a temperature range of -65°C to +150°C. The device exhibits excellent stability with 2% or 2 ohms maximum absolute minimum resistance tolerance, infinite resolution, and 12 turns of effective travel with 200 rotational life cycles. Its sealed construction, compliance with MIL-PRF-39035 high-reliability specifications, and 0.1% failure rate rating make it suitable for demanding applications including aerospace, military electronics, and precision instrumentation where reliable fine-tuning and long-term performance are essential.

Search Keywords: RJR26FX202P

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Bourns
部件编号:
RJR26FX202P
计量单位:
Per Each
RoHS:
No
HTS:
8533408050
COO:
IE
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
12(Elec) Tur ns
Termination Style:
Pin
Power Rating:
0.25 (1/4) W
Resistance Value:
2 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
7.37 x 4.32 x 6.35 mm
Operating Temperature:
-65 to 150 °C
Switch Option:
No
Number of Elements:
1

有存货: 92

Ships today, if you order in

库存数量的起订量: 5

缺货数量的起订量: 50

工厂交货期 10 周

PRICE (USD)

数量
Unit Price
5
$9.47
10
$9.45
25
$9.42
50
$9.40
100
$7.05
150
$6.58
200 +
$6.45
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南
