HCTSM80101AAL-E
Pulse Transformers - Primary Inductance - 250µH - 350mA - Turns ratio 1:1 ...
描述
HCTSM80101AAL-E is a high-clearance and creepage distance isolation transformer designed for automotive-grade power supply applications, featuring a toroid core for high coupling and low radiation. The transformer provides reinforced insulation rated for 800 Vrms and 1000 Vpeak working voltage, with a primary inductance of 250 µH at 100 kHz and 1 V, and a leakage inductance of 0.8 µH maximum. It operates over a temperature range of -40°C to +125°C with a rated current of 350 mA AC, and meets AEC-Q200 compliance, RoHS requirements, and UL 62368-1 recognition. The device is ideal for isolation power supplies using TI SN6501, SN6505B, and Nexperia NXF6501-Q100 controllers, offering high reliability and safety in automotive and industrial power conversion systems.
搜索关键词: HCTSM80101AALE
规格
常见问题
什么产品可以替代 HCTSM80101AAL-E？
HCTSM80101AAL-E 的推荐替代产品是 Bourns 的 HCTSM80101AAL-E1，可从 Master Electronics 购买。
HCTSM80101AAL-E 是否符合 RoHS 标准？
是的，HCTSM80101AAL-E 符合 RoHS 标准。
HCTSM80101AAL-E 的交货期是多少？
HCTSM80101AAL-E 的标准交货期约为 16 周。有库存的数量由 Master Electronics 发货。
有存货: 1,400
可立即发货
库存数量的起订量: 100
缺货数量的起订量: 625
工厂交货期 16 周
