CR0201-FW-1002GLF by bourns
图片仅供参考 - 请查看制造商规格
Bourns 授权经销商

CR0201-FW-1002GLF

Thick Film Chip Resistor - 1/20 W - 10 Kohm ±1% - ±200ppm/°C - SMD 0201 - RoHS Compliant - Tape&Reel ...

查看数据表 询问数据表
符合 RoHS
REEL 包装
附件
请求编程报价
合规证书

描述

CR0201-FW-1002GLF is a thick film chip resistor designed for compact, high-density circuit applications. It features a power rating of 1/20 W at 70°C, a maximum working voltage of 30 V, and a maximum overload voltage of 50 V, with an operating temperature range of -55°C to +125°C. The resistor offers ±1% tolerance with a temperature coefficient of -200 to ±600 ppm/°C, tight tolerance of bottom electrode width, and a three-layer termination process with nickel barrier for excellent solderability and leaching prevention. It is RoHS compliant and supplied in paper tape and reel packaging, making it ideal for automated assembly in consumer electronics, telecommunications, and industrial control applications where space constraints and reliability are critical.

搜索关键词: CR0201FW1002GLF

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Bourns
部件编号:
CR0201-FW-1002GLF
计量单位:
每 Each
RoHS:
Yes
HTS:
8533210030
COO:
TW
ECCN:
EAR99
卷盘包装: 此信息适用于希望按制造商标准包装数量的倍数购买的客户。最低订购数量和要求的订购倍数会与价格和库存信息一同显示。
10000
封装类型:
REEL
电阻值:
10 KOhm
额定功率:
0.05 (1/20) W
公差:
1 %
外壳尺寸:
0201
温度系数:
±200 ppm/°C
工作温度:
-55 to 125 °C
包装方式:
Tape and Reel

常见问题

CR0201-FW-1002GLF 是否符合 RoHS 标准？

是的，CR0201-FW-1002GLF 符合 RoHS 标准。

CR0201-FW-1002GLF 的交货期是多少？

CR0201-FW-1002GLF 的标准交货期约为 12 周。有库存的数量由 Master Electronics 发货。

有存货: 290,000

可立即发货

最小订购数量: 10000

此消息模板用于通知联盟会员某个订单已付款。当金额被扣款时，订单会获得已付款状态。: 10000

工厂交货期 12 周

价格 (USD)

数量
单价
10,000
$0.0044
30,000
$0.0032
50,000
$0.0032
100,000
$0.0026
250,000
$0.0024
500,000
$0.0023
1,000,000 +
$0.0023
卷盘包装
登录以获取特别价格
