95A1A-B28-A13L by bourns
Image is representational - see mfr. specs

95A1A-B28-A13L

Bourns

Res Cermet POT 5K Ohm 10% 2W 1(Elec)/1(Mech)Turn 6.35mm (34.93 X 15.88 X 22.55mm) Solder Lug Panel Mount ...

产品说明书
符合 RoHS 规定
TRAY 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 95A1A-B28-A13L is a Model 95 single-turn panel control potentiometer featuring triangle-pattern solder lugs and a 7/8" (28 mm) metal plain bushing with a 10 mm diameter and 9 mm length. This device uses a cermet resistive element with a linear taper (H code) and ±5% tolerance, supporting resistance values from 100 ohms to 1 megohm. The potentiometer is available with standard shaft lengths of 16.0 mm (0.630") or 22.0 mm (0.866"), with shaft type "V" dimensions of 1.50 ± 0.25 mm diameter. It features virtually infinite electrical circuit isolation and is RoHS compliant, making it suitable for audio equipment, industrial control panels, and consumer electronics requiring precise resistance adjustment with reliable solder lug termination.

Search Keywords: 95A1AB28A13L

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Bourns
部件编号:
95A1A-B28-A13L
计量单位:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
MX
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
45
Package Type:
TRAY
Mounting:
Panel Mount
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Solder
Power Rating:
2 W
Resistance Value:
5 KOhm
Tolerance:
10 %
Temperature Coefficient:
±150 ppm/°C
Dimension:
34.93 x 15.88 x 22.55 mm
Operating Temperature:
-40 to 125 °C
Switch Option:
No
Number of Elements:
1

有存货: 72

Ships today, if you order in

Minimum Order Quantity: 45

Multiple: 45

工厂交货期 7 周

PRICE (USD)

数量
Unit Price
45
$5.14
90
$4.95
135
$4.94
270
$4.79
540
$4.78
1,035
$4.73
2,520
$4.67
5,040 +
$4.66
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南
