5900-153-RC by bourns
Image is representational - see mfr. specs

5900-153-RC

Bourns

High Current RF Choke Bobbin Core 15mH 10% 1KHz Ferrite 190mA 11.5Ohm DCR AXL ...

产品说明书
符合 RoHS 规定
TRAY 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 5900-153-RC is a high-current choke from Bourns' 5900 Series, designed for EMI filtering and power supply applications requiring high inductance values. It features a ferrite bobbin core with 15,000 µH (15 mH) inductance at 1 kHz, a maximum DC resistance of 11.5 O, and a self-resonant frequency of 0.25 MHz. The component is rated for a saturation current of 0.21 A and a continuous rated current of 0.19 A, with VW-1 rated shrink tubing covering the winding for safety and dielectric strength of 2500 Vrms. Operating over a temperature range of -40°C to +125°C, this choke is ideal for high-inductance filtering in power conversion circuits, audio equipment, and industrial power supplies where space constraints and high current handling are critical design considerations.

Search Keywords: 5900153RC

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Bourns
部件编号:
5900-153-RC
计量单位:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
TW
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
864
Package Type:
TRAY
Inductance:
15 mH
Type:
High Current RF Choke
Impedance:
N/A
Lead Pitch:
N/R
Tolerance:
10 %
Technology:
Bobbin Core
Maximum DC Resistance:
11.5 Ohm
Maximum DC Current:
190 mA
Protection Style:
N/A
Packaging:
N/A

有存货: 2,711

Ships today, if you order in

库存数量的起订量: 25

缺货数量的起订量: 216

工厂交货期 16 周

PRICE (USD)

数量
Unit Price
25
$1.65
50
$1.64
100
$1.63
216
$1.62
432
$1.23
648
$1.15
864 +
$1.13
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
