4605X-101-152LF by bourns
Image is representational - see mfr. specs

4605X-101-152LF

Bourns

Res Thick Film NET 1.5K Ohm 2% 0.63W A±100ppm/A°C BUS Conformal Coated 5-Pin SIP Pin Thru-Hole Bulk ...

产品说明书
符合 RoHS 规定
BULK 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 4605X-101-152LF is a thick-film conformal SIP resistor network featuring a bussed electrical configuration (101 circuit) with 1,500 ohms resistance value and ±2% tolerance. It incorporates multiple thick-film resistors of equal value, each connected between a common bus (pin 1) and separate pins, with Sn/Ag/Cu-plated RoHS-compliant terminations. The device operates over a temperature range of -55°C to +125°C with a maximum operating voltage of 100 V, a temperature coefficient of resistance of ±100 ppm/°C (for 50 O to 2.2 MO), and a dielectric withstanding voltage of 200 VRMS. The package delivers 0.63 watts at 70°C ambient temperature and features a low-profile epoxy resin body compatible with DIP layouts. This resistor network is ideal for applications requiring precision termination, signal conditioning, and impedance matching in DRAM, SCSI, and R/2R ladder network circuits.

Search Keywords: 4605X101152LF

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Bourns
部件编号:
4605X-101-152LF
计量单位:
Per Each
RoHS:
Yes
HTS:
8533100020
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
BULK
Case Size:
N/R
Circuit Designator:
BUS
Number of Resistors:
4
Number of Terminals:
5
Power Rating:
0.63 W
Power Rating per Resistor:
0.2 (1/5) W
Resistance Value:
1.5 KOhm
Tolerance:
2 %
Temperature Coefficient:
±100 ppm/°C
Termination Style:
Pin

有存货: 9,000

可立即发货

Minimum Order Quantity: 1000

Multiple: 1000

工厂交货期 15 周

数量
Unit Price
1,000
$0.1092
3,000
$0.0873
8,000
$0.0723
25,000
$0.0700
50,000
$0.0697
100,000
$0.0693
150,000
$0.0690
250,000 +
$0.0686
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南
