3683S-1-502L by bourns
图片仅供参考 - 请查看制造商规格
Bourns 授权经销商

3683S-1-502L

Digital Precision Potentiometer - 5K Ohms - 2W - 23.62 X 42.32mm - Solder Lug - Panel Mount. ...

查看数据表 询问数据表
符合 RoHS
TRAY 包装
附件
请求编程报价
合规证书

描述

The 3683S-1-502L is a 5kR 2W 3-gang snap-in panel-mounting digital precision potentiometer with thumbwheel switch adjustment. The potentiometer features tinned solder lugs terminals for 3 #20AWG wires, ±1° maximum total resistance shift and digital display provides excellent readability. Rear solder terminals fit standard interconnections. In-line digital readout. Convenient snap-in mounting with bezel. Rectangular to match other panel components. Operating temperature ranges from -25°C to +85°C.

搜索关键词: 3683S1502L

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Bourns
部件编号:
3683S-1-502L
计量单位:
每 Each
RoHS:
Yes
HTS:
8533408050
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1
封装类型:
TRAY
安装方式:
Panel Mount
匝数:
N/A
端接方式:
Solder
额定功率:
2 W
电阻值:
5 KOhm
公差:
3 %
温度系数:
±100 ppm/°C
尺寸:
23.62 x 42.32 mm
工作温度:
-25 to 85 °C
开关选项:
No11446
元件数量:
111435

FREQUENTLY ASKED QUESTIONS

Is 3683S-1-502L RoHS compliant?

Yes, 3683S-1-502L is RoHS compliant.

What is the lead time for 3683S-1-502L?

The standard lead time for 3683S-1-502L is approximately 6 days. In-stock quantities ship from Master Electronics.

有存货: 91

发货 today, 输入设置值。

工厂交货期 6 周

价格 (USD)

数量
单价
1
$62.15
5
$58.01
10
$52.46
25
$47.68
50
$45.34
100
$43.42
250 +
$42.82
登录以获取特别价格 点击询价 价格匹配请求

工具/3D模型

产品指南

产品更改
