3500S-2-501L by bourns
图片仅供参考 - 请查看制造商规格
Bourns 授权经销商

3500S-2-501L

Res Wirewound POT 500 Ohm 3% 2W 10(Elec)/10(Mech)Turns 6.34mm (22.23 X 46.04mm) Solder Lug Panel Mount ...

查看数据表 询问数据表
符合 RoHS
TRAY 包装
附件
请求编程报价
合规证书

描述

The 3500S-2-501L is a precision wirewound potentiometer designed for high-accuracy resistance adjustment applications. It features a 10-turn mechanical angle of 3600° ±10° with an effective electrical angle of 3600° ±10°, -0°, and operates with a standard resistance range of 50 to 200 kO with ±3% total resistance tolerance and ±0.20% independent linearity. The potentiometer incorporates a bushing mount with a 3/8"-32 2A thread, sealable construction rated IP 65, and gold-plated solder lugs for reliable connections. Mechanical specifications include a maximum starting and running torque of 0.42 N-cm (0.6 oz.-in.), stop strength of 67.8 N-cm (96 oz.-in.) minimum, and backlash of 1.0° maximum. The device operates over a temperature range of +1°C to +125°C with a temperature coefficient of ±50 ppm/°C maximum, making it suitable for precision instrumentation, control systems, and industrial applications requiring stable, accurate resistance values.

搜索关键词: 3500S2501L

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Bourns
部件编号:
3500S-2-501L
计量单位:
每 Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
5
封装类型:
TRAY
安装方式:
Panel Mount
匝数:
10(Elec),10(Mech) Turns
端接方式:
Solder
额定功率:
2 W
电阻值:
500 Ohm
公差:
3 %
温度系数:
±50 ppm/°C
尺寸:
46.04 x 22.23 mm
工作温度:
1 to 125 °C

常见问题

3500S-2-501L 是否符合 RoHS 标准？

是的，3500S-2-501L 符合 RoHS 标准。

3500S-2-501L 的交货期是多少？

3500S-2-501L 的标准交货期约为 30 周。有库存的数量由 Master Electronics 发货。

有存货: 14

可立即发货

已订购: 50   可以发货 10/12/26

缺货数量的起订量: 13

工厂交货期 30 周

价格 (USD)

数量
单价
1
$115.21
5
$114.92
10
$114.64
13
$114.35
25
$73.18
38
$57.17
50 +
$56.03
