3362H-1-502LF by bourns
Image is representational - see mfr. specs

3362H-1-502LF

Bourns

Res Cermet Trimmer 5K Ohm 10% 0.5W(1/2W) 1(Elec)/1(Mech)Turn 2.77mm (6.6 X 6.99 X 4.7mm) Pin Thru-Hole Tube ...

产品说明书
符合 RoHS 规定
TUBE 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 3362H-1-502LF is a 1/4" square Trimpot® trimming potentiometer manufactured by Bourns, featuring a 5 kO resistance value with single-turn cermet construction. This sealed, miniature potentiometer is designed with a rotor optimized for automatic machine adjustment interfaces and withstands harsh environments and immersion cleaning processes. Key electrical characteristics include ±10% resistance tolerance, ±0.05% adjustability in voltage divider mode, 240° nominal adjustment angle, and 1,000 megohms minimum insulation resistance at 500 VDC. The device operates across a temperature range of -55°C to +125°C with a power rating of 0.50 watts at 70°C, and features 100% tin-plated (RoHS compliant) terminations. This trimmer is ideal for precision calibration and adjustment applications in industrial control systems, instrumentation, and sealed electronic assemblies where reliability and environmental resistance are critical.

Search Keywords: 3362H1502LF

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Bourns
部件编号:
3362H-1-502LF
计量单位:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
1(Elec),1(Mech) Tur ns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
5 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
6.6 x 6.99 x 4.7 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

有存货: 472

可立即发货

Minimum Order Quantity: 250

Multiple: 250

工厂交货期 7 周

PRICE (USD)

数量
Unit Price
250
$1.062
500
$0.986
1,000
$0.983
2,500
$0.919
5,000
$0.895
7,500
$0.872
10,000
$0.870
15,000 +
$0.867
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南
