3296Z-1-205LF by bourns
图片仅供参考 - 请查看制造商规格
Bourns 授权经销商

3296Z-1-205LF

Res Cermet Trimmer 2M Ohm 10% 0.5W(1/2W) 25(Elec)Turn 2.19mm (11.05 X 4.83 X 10.03mm) Pin Thru-Hole Tube ...

查看数据表
符合 RoHS
TUBE 包装
附件
请求编程报价
合规证书

描述

The 3296Z-1-205LF is a 3/8" square Trimpot trimming potentiometer manufactured by Bourns, designed for precision resistance adjustment in industrial applications. This multiturn cermet device features a 2 megohm resistance value with ±10% tolerance, infinite resolution, and a sealed chevron design for environmental protection. It offers exceptional adjustability with voltage accuracy of ±0.01% and resistance accuracy of ±0.05%, along with an effective travel of 25 turns nominal. The potentiometer operates across a wide temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C, and is rated for 0.5 watt at 70°C. Its RoHS-compliant termination (100% tin-plated) and solderable pins make it suitable for automated assembly in instrumentation, data acquisition, and precision control circuits where reliable, repeatable adjustment is essential.

搜索关键词: 3296Z1205LF

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Bourns
部件编号:
3296Z-1-205LF
计量单位:
每 Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
供应商标准包装: 供应商原始包装中所含物品的数量、长度、重量或体积，以便高效存储、搬运和配送。
100
封装类型:
TUBE
安装方式:
Through Hole
匝数:
25(Elec) Turns
端接方式:
Pin
额定功率:
0.5 (1/2) W
电阻值:
2 MOhm
公差:
10 %
温度系数:
±100 ppm/°C
尺寸:
11.05 x 4.83 x 10.03 mm
工作温度:
-55 to 125 °C
开关选项:
No
元件数量:
1

常见问题

3296Z-1-205LF 是否符合 RoHS 标准？

是的，3296Z-1-205LF 符合 RoHS 标准。

3296Z-1-205LF 的交货期是多少？

3296Z-1-205LF 的标准交货期约为 7 周。有库存的数量由 Master Electronics 发货。

有存货: 546

可立即发货

最小订购数量: 100

此消息模板用于通知联盟会员某个订单已付款。当金额被扣款时，订单会获得已付款状态。: 100

工厂交货期 7 周

价格 (USD)

数量
单价
100
$1.127
300
$1.050
500
$1.047
1,000
$0.861
2,500
$0.833
5,000
$0.822
7,500
$0.812
10,000 +
$0.810
供应商标准包装
登录以获取特别价格

工具/3D模型

产品指南
