3296X-1-102RLF by bourns
Image is representational - see mfr. specs

3296X-1-102RLF

Bourns

Res Cermet Trimmer 1K Ohm 10% 0.5W(1/2W) 25(Elec)Turn 2.19mm (11.05 X 4.83 X 10.03mm) Pin Thru-Hole T/R ...

产品说明书
符合 RoHS 规定
REEL 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 3296X-1-102RLF is a 3/8" square Trimpot® trimming potentiometer manufactured by Bourns, featuring a 1 kO resistance value with ±10% tolerance and multiturn cermet construction for precise adjustment. This sealed, industrial-grade component offers 25 turns nominal effective travel with infinite resolution and ±0.05% resistance adjustability, making it suitable for applications requiring fine-tuned calibration. The device operates across a temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C, and is rated for 0.5 watts at 70°C. The side-adjust (3296X) configuration with solderable pins and RoHS-compliant termination (100% tin-plated) makes it ideal for industrial instrumentation, signal conditioning, and precision measurement systems where reliable long-term performance and environmental stability are essential.

Search Keywords: 3296X1102RLF

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Bourns
部件编号:
3296X-1-102RLF
计量单位:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
1000
Package Type:
REEL
Mounting:
Through Hole
Number of Turns:
25(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
1 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
11.05 x 4.83 x 10.03 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

有存货: 640

Ships today, if you order in

Minimum Order Quantity: 250

工厂交货期 7 周

PRICE (USD)

数量
Unit Price
250
$1.70
500
$1.69
1,000
$1.59
3,000
$1.55
5,000
$1.52
8,000
$1.51
10,000
$1.50
15,000 +
$1.49
Reel Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南
