Q22F1BXXR12E
22mm dia panel mount indicator - Uni Color LED - Flush Mount - Red - 12VDC - Solder Lug/Faston Terminals - Plated Brass - Black - IP67 ...
描述
Q22F1BXXR12E is a Ø22 mm panel mount LED indicator designed for industrial control and signaling applications. It features a rear epoxy body with M22 x 1.0 thread mounting, solder lug/faston terminals (2.8 x 0.8 mm), and 200 mm ±10 mm wire leads for flexible installation. The indicator has a 16.75 mm colored diffused epoxy lens or super bright LED option, with a viewing angle of 30–100° depending on the model configuration. Operating temperature range is -40°C to +85°C for the rear epoxy body, with IP67 sealing available per EN60529, and a life expectancy of 100,000 hours. The product is commonly used in automotive dashboards, industrial control panels, and equipment status indication where reliable, long-life LED signaling is required.
搜索关键词: Q22F1BXXR12E
规格
常见问题
Q22F1BXXR12E 是否符合 RoHS 标准？
是的，Q22F1BXXR12E 符合 RoHS 标准。
Q22F1BXXR12E 的交货期是多少？
Q22F1BXXR12E 的标准交货期约为 16 周。有库存的数量由 Master Electronics 发货。
有存货: 54
发货 today, 输入设置值。
工厂交货期 16 周
数据表
