AT04-12PA-RD01 by amphenol sine systems
图片仅供参考 - 请查看制造商规格
Amphenol Sine Systems 授权经销商

AT04-12PA-RD01

12-Way Receptacle, Male Connector with A Position Key and Extended Shroud, Reduced Diameter Seal (E-Seal) ...

查看数据表 询问数据表
符合 RoHS
EACH 包装
附件
请求编程报价
合规证书

描述

AT04-12PA-RD01 is a 12-position receptacle connector with pin contacts from the Amphenol AT Series, designed for heavy-duty industrial applications requiring reliable environmental sealing. The connector features a thermoplastic housing rated UL94-V0 with excellent UV resistance and an integrated latching system for secure electrical and mechanical connections. It is rated IP67, IP68, and IP69K in mated condition, providing dust-tight protection and waterproof performance up to 1M for 24 hours as well as high-pressure waterproof capability. The connector supports a maximum current of 13A (Size 16 contacts) with a voltage rating of 250V and operates over a temperature range of -55°C to +125°C. Common applications include industrial equipment, transportation, and outdoor environments where resistance to fluids such as gas, oil, and acid is required.

搜索关键词: AT0412PARD01

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Amphenol Sine Systems
部件编号:
AT04-12PA-RD01
计量单位:
每 Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
880
封装类型:
EACH

常见问题

AT04-12PA-RD01 是否符合 RoHS 标准？

是的，AT04-12PA-RD01 符合 RoHS 标准。

AT04-12PA-RD01 的交货期是多少？

AT04-12PA-RD01 的标准交货期约为 14 周。有库存的数量由 Master Electronics 发货。

有存货: 504

发货 today, 输入设置值。

已订购: 1,100   可以发货 12/21/26

最小订购数量: 25

工厂交货期 14 周

价格 (USD)

数量
单价
25
$1.81
100
$1.68
250
$1.59
880
$1.47
1,760
$1.41
2,640
$1.37
5,280
$1.30
7,920 +
$1.26
供应商标准包装
