145101-01-36.00
RF Cable Assembly - SMB Straight Plug to SMB Straight Plug on RG-316 cable - 3 feet ...
描述
145101-01-36.00 is an SMB crimp plug to SMB crimp plug coaxial cable assembly designed for RF and microwave applications. The assembly utilizes RG-316/U coaxial cable with a nominal impedance of 50 ohms and operates across a frequency range of DC to 3.0 GHz. The cable length is 36.00 inches (0.914 meters) with a tolerance of ±0.50 inches, and the assembly features SMB crimp connectors (P/N: 142186) on both ends with heat shrink tubing for strain relief. The design meets stringent electrical requirements including a maximum VSWR of 1 and passes continuity and high-potential testing at 500 VRMS, making it suitable for test equipment, RF instrumentation, and communication systems requiring reliable impedance-matched connections.
搜索关键词: 145101013600
规格
常见问题
145101-01-36.00 是否符合 RoHS 标准？
是的，145101-01-36.00 符合 RoHS 标准。
145101-01-36.00 的交货期是多少？
145101-01-36.00 的标准交货期约为 14 周。有库存的数量由 Master Electronics 发货。
有存货: 0
制造商库存: 1 可以发货 10/26/26
已订购:
50
可以发货 12/4/26
工厂交货期 14 周 可以发货 1/19/27
Customer Drawings
数据表
