132170-10 by amphenol rf
Image is representational - see mfr. specs

132170-10

Amphenol RF

Conn SMA Adapter ST Panel Mount RCP/RCP Gold ...

产品说明书
符合 RoHS 规定
BAG 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 132170-10 is an SMA bulkhead jack-to-jack adapter designed for RF and microwave interconnect applications. It features a 50-ohm impedance with a frequency range of 0–18 GHz and maintains a maximum VSWR of 1.300 (-17.7 dB), ensuring excellent signal integrity across the operating band. The adapter is constructed with brass body and hex nut with gold plating, beryllium copper gold-plated contacts, and a silicone rubber gasket, providing durability and corrosion resistance. It operates reliably over a temperature range of -65°C to +165°C with a minimum dielectric withstanding voltage of 1000 VRMS and supports 500 mechanical cycles minimum. This adapter is ideal for test equipment, communication systems, and RF instrumentation where reliable, low-loss connections are essential.

Search Keywords: 13217010

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Amphenol RF
部件编号:
132170-10
Alias/AKA:
SMA7471A1-3GT50G-50
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
SMA Adapter
Impedance:
N/A
Operating Frequency:
N/A
Gender:
RCP/RCP
Mounting:
Panel Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
N/A
Operating Temperature:
N/A
Dimension:
22.5 x 13 mm

有存货: 206

可立即发货

工厂库存: 1   可以发货 6/29/26

工厂交货期 13 周 可以发货 9/15/26

PRICE (USD)

数量
Unit Price
1
$28.29
5
$19.14
10
$15.28
25
$15.13
50
$14.99
100
$14.95
250 +
$14.62
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南
