031-9-75RFX by amphenol rf
Image is representational - see mfr. specs

031-9-75RFX

Amphenol RF

Conn BNC Adapter 0Hz to 4GHz 75Ohm RA RCP/PL Gold ...

产品说明书
符合 RoHS 规定
BAG 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 031-9-75RFX is a 75 O BNC angle jack-plug adapter designed for commercial-grade RF connectivity applications. This connector features a nickel-plated brass body with gold-plated beryllium copper or phosphor bronze contacts, providing excellent corrosion resistance and reliable signal transmission. The adapter operates across a frequency range of DC to 1 GHz with a nominal impedance of 75 O, delivering a VSWR of 1.0 + 0.25f (GHz) and insertion loss of 0.2 dB maximum at 3 GHz. It employs a 2-stud bayonet lock coupling mechanism (MIL-STD-348) with a coupling torque range of 0.6 to 2.5 in-lbs, ensuring secure mating with quarter-turn engagement. The connector is rated for operation from -65°C to +165°C and supports 500 mating cycles minimum, making it suitable for test equipment, instrumentation, and video/RF signal distribution systems requiring 75 O impedance matching.

Search Keywords: 031975RFX

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Amphenol RF
部件编号:
031-9-75RFX
Alias/AKA:
B5072B1-001-ND3G-75
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
BNC Adapter
Impedance:
75 Ohm
Operating Frequency:
0 to 1 Hz to GHz
Gender:
RCP/PL
Mounting:
N/A
Body Orientation:
Right Angle
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
-65 to 165 °C
Dimension:
N/A

有存货: 383

可立即发货

工厂库存: 457   可以发货 6/1/26

Minimum Order Quantity: 5

工厂交货期 13 周 可以发货 8/17/26

PRICE (USD)

数量
Unit Price
5
$8.88
25
$8.36
50
$8.13
100
$6.18
250
$5.86
500
$4.98
1,000 +
$4.32
Log in for special pricing Click for Quote Price Match Request
