MS3102A18-4S by amphenol industrial operations
图片仅供参考 - 请查看制造商规格
Amphenol Industrial Operations 授权经销商

MS3102A18-4S

Conn Circular SKT 4 POS Solder Cup ST Box Mount 4 Terminal 1 Port Automotive ...

查看数据表 询问数据表
不符合 RoHS 规定
包装
附件
请求编程报价
合规证书

描述

MS3102A18-4S is a MIL-DTL-5015 Type standard cylindrical box mounting receptacle connector designed for military and aerospace applications requiring reliable electrical connections. The connector features an 18-size shell with a 4-contact insert arrangement, constructed from high-grade aluminum alloy with electrically conductive cadmium plate finish and olive drab chromate after-treat for superior corrosion resistance. Contacts are available in both solder and crimp versions, machined from copper alloy with silver plated finish for maximum corrosion resistance and low millivolt drop. The resilient neoprene inserts provide high dielectric strength, high arc resistance, and resistance to vibration, with the capability to pressurize either pin or socket insert. This connector is widely used in military equipment, aerospace systems, and other demanding environments where environmental sealing, durability, and reliable signal transmission are critical requirements.

搜索关键词: MS3102A184S

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Amphenol Industrial Operations
部件编号:
MS3102A18-4S
别名/又称:
61-168218-04S
计量单位:
每 Each
RoHS:
No
HTS:
8536694020
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1

常见问题

MS3102A18-4S 是否符合 RoHS 标准？

不，MS3102A18-4S 不符合 RoHS 标准。

MS3102A18-4S 的交货期是多少？

MS3102A18-4S 的标准交货期约为 16 周。有库存的数量由 Master Electronics 发货。

有存货: 44

可立即发货

已订购: 56   可以发货 10/13/26

最小订购数量: 5

工厂交货期 16 周

价格 (USD)

数量
单价
5
$21.38
25
$19.84
50
$18.51
100
$18.42
250
$17.64
500
$16.98
1,000 +
$16.32
登录以获取特别价格
