AZKUP-1C-120AK by american zettler
Image is representational - see mfr. specs

AZKUP-1C-120AK

American Zettler

13AMP General Purpose Power Relay 12VDC coil SPDT ...

产品说明书
符合 RoHS 规定
Box 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

AZKUP-1C-120AK is a single-pole double-throw (SPDT) general-purpose power relay designed for AC coil operation at 120 VAC. The relay features silver cadmium oxide contacts with gold flash on movable contacts and fine silver with gold flash on stationary contacts, providing reliable switching with contact resistance less than 50 milliohms. It is rated for 13 A at 120 VAC, 1/3 HP at 120 VAC, and 10 A at 28 VDC, with a nominal coil power of 2 VA and coil resistance of 2025 ohms. The relay operates with a must-operate voltage of 102 VAC and maximum continuous voltage of 156 VAC, featuring a flange mount cover design with quick-connect male terminals. With mechanical life expectancy of 1×107 operations and electrical life of 1×105 operations at rated load, this relay is suitable for industrial control, HVAC systems, and general-purpose switching applications requiring robust AC coil operation.

Search Keywords: AZKUP1C120AK

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
American Zettler
部件编号:
AZKUP-1C-120AK
计量单位:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
96
Package Type:
Box
Relay Construction:
Non-Latching10725
AC Coil Voltage:
120 V
DC Coil Voltage:
N/A
Contact Arrangement:
SPDT10703
Mounting:
Flange Mount10716
Termination Style:
Solder Lug10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-45 to 55 °C
Coil Resistance:
2.025 KOhm

有存货: 93

Ships today, if you order in

库存数量的起订量: 5

缺货数量的起订量: 24

工厂交货期 14 周

PRICE (USD)

数量
Unit Price
5
$20.94
10
$18.29
24
$17.11
48
$16.57
72
$15.82
96 +
$15.50
Suppliers Standard Package
