AZ2800-2C-277A by american zettler
Image is representational - see mfr. specs

AZ2800-2C-277A

American Zettler

40AMP Power Relay 277VAC coil SPDT ...

产品说明书
符合 RoHS 规定
Tray 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The AZ2800-2C-277A is a 40 A miniature power relay designed for switching high-current AC loads in industrial and commercial applications. It features dual-pole contact arrangements (DPST with 2 Form A or DPDT with 2 Form C contacts) with a 277 VAC nominal AC coil rated at 14.4 mA nominal current and 4700 O coil resistance (60 Hz). The relay meets 8 mm creepage and 4 kV dielectric strength requirements, with contact ratings of 40 A at 277 VAC resistive (30k cycles), 30 A at 277 VAC general use (100k cycles), and operates with a 15 ms typical operate time and 10 ms typical release time. It is rated for -40°C to 65°C ambient operating temperature, withstands 0.062" displacement at 10–55 Hz vibration and 10 g operational shock, and is housed in a PBT polyester enclosure with quick-connect tab terminals. Common applications include HVAC systems, lighting control, motor starters, and power distribution in commercial buildings where 277 VAC switching is required.

Search Keywords: AZ28002C277A

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
American Zettler
部件编号:
AZ2800-2C-277A
计量单位:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Tray
Relay Construction:
Non-Latching10725
AC Coil Voltage:
277 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT10703
Mounting:
Flange Mount10716
Termination Style:
Quick Connect10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-40 to 65 °C

有存货: 3

可立即发货

Buy all 3 in-stock or the regular minimum order quantity of 5

已订购: 100   可以发货 8/19/26

Stock lot only: 3

Minimum Order Quantity: 5

工厂交货期 16 周

PRICE (USD)

数量
Unit Price
1
$25.553
5
$23.230
10
$21.610
25
$19.450
50
$18.730
100
$17.640
300
$17.220
500 +
$16.620
Suppliers Standard Package
