6713-WH005 by alpha wire
Image is representational - see mfr. specs

6713-WH005

Alpha Wire

Hook Up Wire - Stranded - 22 (7/30) AWG - 600V - mPPE - White - 100 ft - Tinned Copper ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

6713-WH005 is a 22 AWG single-conductor hookup wire manufactured by Alpha Wire, designed for general-purpose electrical connections in applications requiring UL AWM/STYLE 11028 compliance. The wire features a 7/30 stranded tinned copper conductor with a 0.0095" wall nominal modified polyphenylene ether insulation, providing an overall diameter of 0.049 ± 0.002 inches. It is rated for 600 V RMS at 105°C continuous operation with VW-1 flame rating and CSA C(RU) AWM I A/B FT1 certification. The wire operates reliably across a temperature range of -40°C to 105°C, has a maximum bend radius of 10 times the cable diameter, and exhibits a conductor DC resistance of 16.2 O/1000 ft at 20°C. This RoHS-compliant wire is ideal for internal wiring in control panels, instrumentation, and general hookup applications where compact gauge and reliable insulation are required.

Search Keywords: 6713WH005

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Alpha Wire
部件编号:
6713-WH005
Alias/AKA:
6713-WHITE-100
计量单位:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
US
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Size:
22 AWG
Conductor Material:
Tinned Copper
Cable Diameter:
1.24 mm
Maximum Voltage Rating:
600 V
Operating Temperature:
-40 to 105 °C
Color:
White
  Different packaging options available.  See Alternatives

有存货: 10

可立即发货

工厂交货期 16 周

PRICE (USD)

数量
Unit Price
1
$73.11
5
$65.54
10
$63.24
25
$59.13
50
$56.16
100
$53.32
250 +
$53.19
