541419-GR005 by alpha wire
Image is representational - see mfr. specs

541419-GR005

Alpha Wire

A 14 AWG single-conductor hook-up wire rated for 600V and suitable for UL Type THHN and THWN applications. ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 541419-GR005 is a single-conductor hook-up wire designed for general-purpose internal wiring. It is constructed with a 14 AWG stranded (19/.0147) bare copper conductor for excellent conductivity and flexibility. The insulation consists of a 0.016" PVC wall with a protective 0.005" nylon jacket, resulting in a nominal outer diameter of 0.116 inches. This wire is UL listed as Type THHN for use up to 90°C and Type THWN for wet or dry conditions up to 75°C, both with a voltage rating of 600 VRMS. Its robust design and wide operating temperature range make it ideal for wiring control panels, machine tools, and other electrical equipment.

Search Keywords: 541419GR005

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Alpha Wire
部件编号:
541419-GR005
Alias/AKA:
541419-GREEN-100
计量单位:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
US
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Size:
14 AWG
Conductor Material:
Bare Copper
Cable Diameter:
2.94 mm
Maximum Voltage Rating:
600 VAC
Color:
Green
  Different packaging options available.  See Alternatives

有存货: 7

可立即发货

工厂交货期 13 周

数量
Unit Price
1
$47.45
5
$42.34
10
$41.08
25
$39.89
50
$37.70
100
$36.70
250 +
$36.21
Suppliers Standard Package
