3057-YL005 by alpha wire
Image is representational - see mfr. specs

3057-YL005

Alpha Wire

Hook-up Wire 16AWG 2.41mm Tinned Copper - Yellow - 300VAC - 30.48m (100ft)/Spool ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 3057-YL005 is a single-conductor hookup wire designed for general-purpose electrical interconnections and wiring applications. It features a 16 AWG tinned copper conductor (26/30 stranding) with a nominal 0.016" wall PVC insulation, providing a total diameter of 0.092" ± 0.002". The wire is rated for 300 V RMS and operates across a temperature range of -40°C to 105°C, with a maximum pull tension of 20.4 lbs and a minimum bend radius of 10 times the cable diameter. Electrical characteristics include a nominal inductance of 0.04 µH/ft and a conductor DC resistance of 4.4 O/1000 ft at 20°C. This wire is commonly used in control circuits, instrumentation, and low-voltage power distribution where reliable insulation and temperature stability are required, and it is available in multiple colors including yellow (YL005 designation) and complies with RoHS and REACH regulations.

Search Keywords: 3057YL005

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Alpha Wire
部件编号:
3057-YL005
Alias/AKA:
3057-YELLOW-100
计量单位:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Size:
16 AWG
Bunch Stranding:
26x30
Conductor Material:
Tinned Copper
Cable Diameter:
2.38 mm
Maximum Voltage Rating:
300 V
Operating Temperature:
-40 to 105 °C
Color:
N/R
  Different packaging options available.  See Alternatives

有存货: 4

可立即发货

工厂交货期 10 周

PRICE (USD)

数量
Unit Price
1
$148.75
5
$134.25
10
$128.54
20
$124.32
50
$114.01
100 +
$109.41
