2842/7-RD005
Hook-up Wire 28AWG 0.68mm Silver Plated Copper - Red - 250V - 30.48m (100ft)/Spool ...
描述
The 2842/7-RD005 is a single-conductor hookup wire designed for general-purpose electrical applications requiring reliable insulation and conductivity. It features a 28 AWG (7/36) stranded silver-plated copper conductor with a nominal 0.006" wall PTFE insulation, providing excellent dielectric properties and chemical resistance. The wire is rated for 250V RMS operation and maintains performance across a temperature range of -60°C to +200°C, with a maximum pull tension of 1.37 lbs and a minimum bend radius of 10 times the cable diameter. It complies with military specification MIL-W-16878/6 (Type ET) and NEMA HP3-ETXBGB standards, and is RoHS 2 and REACH compliant. This wire is commonly used in instrumentation, aerospace, and high-temperature applications where superior insulation integrity and temperature stability are essential.
搜索关键词: 28427RD005
规格
有存货: 0
已订购:
10
可以发货 9/11/26
工厂交货期 13 周
价格 (USD)
工具/3D模型
Shrink Tubing
数据表
